915MHz Lora Outdoor Fiberglass Antenna with Clip Code for Base Station
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | xinhongyu |
| Model Number: | 868 fiberglass antenna |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 pieces |
|---|---|
| Price: | $7.50/pieces 10-99 pieces |
|
Detail Information |
|||
| Type: | LoRa/LPWAN Antenna, 868mhz | Type1: | 915mhz |
|---|---|---|---|
| Type2: | 2.4G | Type3: | 5.8G |
| Frequency Range: | 868/915/2400-2500MHz/5150-5850MHz | Color: | Grey |
| Size: | 35*2cm | Weight: | 0.4kg |
| Gain: | 8dBi | ||
Product Description
Product Description
Specification
Item | Specifications | ||
Antenna | Frequency Range | 868-915MHz | |
Gain | 14/12/10/8/5.8dBi | ||
V.S.W.R | ≤1.5 | ||
Impendance | 50Ω | ||
Antenna size | 10cm / 15cm / 20cm /25cm | ||
Polarization | Vertical | ||
Mechanical | Inner Material | Copper tube | |
Connector type | N/SMA or customizable | ||
Mounting Method | N Connector | ||
Environmental | Operating Temperature | -40℃~+80℃ | |
Storage Temperature | -40℃~+85℃ | ||
Environmentally Friendly | ROHS Compliant | ||
